1.Size :1/2"~24" (DN15~DN500)
2.Working Pressure :150Lb~2500Lb
3.Working Temperature :-20ˇăC~200ˇăC
4.Suitable Medium:Water,Oil,Gas and Steam.
5.Forged Materials:A105N,F304,F304L,F316,F316L,F11,F22,F51,F55
Product Feature:
A.End by Flange Butt-Welding Full bore or reduce bore.
B.Blow-out proof stem
C.ISO 5211 mounting pad
D.Fire-Proof and anti-static design as your required
E:PTFE,RPTFE,PPL,Metal seat for your choose
F:Control device:Lever.Pneumatic.
Technical Specification:
A.Design&Manufacture standard: ASME B16.34/BS 5351
B.Screwed Standard: ASME B1.20.1.
C.SW, BW, End: ASME B16.11
D:Test &Inspect standard: API 598
E.Fire Safe by: API 607
F:Face to Face:ASME B16.11 or As client required |
